video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, Engine, Bearing, Gearbox, Motor, Gear
plastic processed :
PP, HDPE, PVC, PE/PP
place of origin :
China
brand name :
DAWSON
voltage :
220V,380V
dimension(l*w*h) :
4.4*3.4*3.6
Clamping Force (kN) :
100
Screw L/D Ratio :
24
screw diameter (mm) :
80 mm
output (kg/h) :
100 kg/h
automation :
Automatic
No. of Screw Heating Zone :
4
screw heating power(kw) :
9 kW
extruder motor power(kw) :
37 kW
mold platen size(width)(mm) :
400 mm
mold platen size(height)(mm) :
540 mm
air pressure(mpa) :
0.8 MPa
air comsumption(m³/min) :
1 m³/min
die head heating power(kw) :
8 kW
power (kw) :
101.2
weight (t) :
8.5
key selling points :
Easy To Operate
warranty :
1 Year
Model NO. :
ABLB80-25L
Station :
Single Station or Double Station
Max. Product Volume :
25L
Clamping System :
Toggle Type Clamping System
Suitable Material :
HDPE,PP,PVC,PS,PETG,LDPE
Made in :
China
Oil Pump Motor Power :
11kw
Head Heating Power :
8kw
Trademark :
DAWSON
Model :
ABLB90
Condition :
New
Warranty of core components :
1 Year
Application :
Bottle
Applicable Industries :
Manufacturing Plant
Showroom Location :
Philippines
Year :
2021
Hollow part volume :
10-30L
Accumulator Capacity(L) :
0 L
Packaging Details :
Blow molding machine are packed with plastic film; auxiliary machines and spare parts are packed with wooden boxes. The loading to containers is done according to weight balance, every package's position is fixed in containers to avoid moving. The photos o
Supply Ability :
20 Set/Sets per Month
Price :
$58,000/sets 1-2 sets
